Are plastic grids less durable?
No, not if you value quality! We offer a 20-year warranty on our ECORASTER products, and as both a manufacturer and a raw material producer, we can guarantee consistently high and reliable quality. Our floor grids are made from recyclable LDPE, which makes them shatter-resistant, weather-resistant, and UV-stable.
Are ECORASTER grids suitable for vehicle traffic?
Yes, ECORASTER grids can be driven over without any problems. Depending on the subgrade and the fill material used, loads of up to 800 tons per square meter have been tested by TÜV. The ECORASTER grids mentioned here can be driven over immediately after installation while they are still empty, which makes filling them considerably easier.
Is the ECORASTER surface considered permeable?
Yes, with more than 95% open surface area, a water column cannot accumulate on a standard ECORASTER surface. The final decision on the credit amount rests with the relevant authority or municipality.
Can snow be cleared from ECORASTER surfaces?
Yes, ECORASTER surfaces can be cleared of snow using de-icing salt, a broom, a snowplow, or a brush roller/milling machine. Avoid clearing the surface with a snow blower. If you clear a surface treated with grit, grit may accumulate after the snow has melted. Simply sweep it back onto the surface.
Can I install ECORASTER without a subbase?
Yes, however, there may be limitations to the performance of the ECORASTER system: If a subbase (water-bearing layer) is not used, surface drainage cannot be guaranteed. In addition, changes in the natural soil can result in unevenness and variations in load-bearing capacity. Thanks to the proven safety interlocking system, no edges or joints are formed.
Do I have to install a border?
No, the design of ECORASTER floor grids includes a number of expansion joints, which eliminate the need for edging. When installing, simply leave a gap of at least 5 cm from the edge. This will create an additional, continuous expansion joint.
How do I calculate the amount of gravel/crushed stone I need?
Before determining how much gravel, crushed stone, etc., you need, you should accurately measure the area. For larger areas, you should use a leveling device or a laser. Calculate the amount needed to fill the grids as follows:
0.95 × area × grid height
What should be kept in mind for heavy-duty and shunting operations?
For areas primarily used by trucks and heavy-duty vehicles (e.g., forklift traffic and turning circles), we recommend installing ECORASTER E50 with a 1–2 cm layer of crushed stone.
Can ECORASTER ground grids be disposed of?
Yes, ECORASTER is a nearly single-material, environmentally neutral recycled product made from LDPE plastic. The trimmings can therefore be recycled without hesitation.
Can ECORASTER ground grids be combined with other products?
No, ECORASTER products cannot be combined with third-party products and can only be expanded with original accessories
What do land use and soil sealing mean?
Today, nearly half of our urban and transportation areas are sealed—that is, built up, concreted, paved, or otherwise mechanically compacted. The soil is cut off from all natural cycles, such as groundwater infiltration, and its vital functions are being lost. Currently, in Germany alone, we are converting approximately 104 hectares of land per day into land-use areas. It should be noted that land use does not automatically mean soil sealing. Nevertheless, the degree of soil sealing stands at around 46 percent.
* Certificates, Approvals & Inspections
To ensure that our ECORASTER ground reinforcement system continues to be delivered in the quality you have come to expect, we regularly undergo voluntary inspections and tests.
NATO-certified: ECORASTER S50
RAL certified: ECORASTER Bloxx, E50 and E40
Cannot find your question or need further information?
Of course, we try to prepare and provide the most important questions, concerns, and suggestions as best we can so that you can obtain detailed information in advance. However, if the answers in our ECORASTER FAQ do not answer all of your questions, we will be happy to advise you personally. Please let us know if we can be of further assistance:
